Apex Deck Gray
Apex Deck Gray


Contact For Availabilty
Description
Description
Description
Apex Deck Grey is a high-performance film-faced plywood panel built on a foundation of 100% exterior-grade Baltic birch. The surface is overlaid with a high-density paper film impregnated with phenol-formaldehyde resin, providing a smooth, durable finish ideal for concrete formwork. All edges are sealed with water-resistant acrylic paint to protect against moisture and increase longevity. The panel is tested to withstand 400–450 cycles on the Taber abrasion test, ensuring long-term durability in demanding site conditions.
This enhanced version of standard film-faced plywood offers a range of improved performance features. It delivers twice the water resistance, superior UV and chemical resistance, and a 50% lower level of formaldehyde emissions. The grey phenolic film eliminates the risk of concrete staining and provides better color stability over time, even with prolonged exposure to sunlight.
Designed specifically for architectural-grade concrete applications, Apex Deck Grey produces a clean, neutral-toned concrete finish that requires less post-processing and delivers a more refined, professional result. Its strength, stability, and clean-release surface make it a reliable material for contractors, architects, and builders who prioritize both performance and appearance in structural formwork.
Specifications
Sheet Size
1220mm х 2440mm, 1250mm х 2500mm, 1525mm x 1525mm, 1525mm х 3050mm
1220mm х 2440mm, 1250mm х 2500mm, 1525mm x 1525mm, 1525mm х 3050mm
1220mm х 2440mm, 1250mm х 2500mm, 1525mm x 1525mm, 1525mm х 3050mm
Material Thickness
6.5mm, 9mm, 12mm, 15mm, 18mm, 19mm, 21mm, 24mm, 27mm, 30m, 35mm, 40mm
Rating
I/I
Strength Characteristics
Strength Characteristics
Thickness of plywood, mm | Bending strength, MPa, mean value | Modulus of Elasticity, MPa, mean value | ||
perpendicular to the fiber | parallel to the fiber | perpendicular to the fiber | parallel to the fiber | |
6,5 | 60 | 85 | 4300 | 9500 |
9 | 65 | 85 | 5700 | 9000 |
12 | 60 | 80 | 6000 | 8500 |
15 | 60 | 80 | 6500 | 8500 |
18 | 75 | 70 | 7000 | 8500 |
19 | 70 | 70 | 7200 | 8000 |
21; 24; 27; 30 | 70 | 70 | 7000 | 8000 |
Applications
Concrete formwork with architectural finish requirements
Precast concrete panel casting
Bridge and infrastructure foundation molds
Commercial and residential construction systems
High-precision structural formwork projects
Projects requiring stain-free, smooth-release plywood surfaces
Key Advantages
Grey phenolic overlay for seamless concrete aesthetics
High Taber abrasion resistance (400–450 cycles)
Superior moisture protection with sealed edges
UV‑stable and chemical‑resistant film
Low‑emission (E1 / EPA TSCA Title VI compliant)
Lightweight yet rugged for easy handling on site
Precisely machined for consistent panel dimensions
